Assignment 3: Drawing Procedures

Consider the following Scheme code.

(define sample
  (drawing-hshift
   (drawing-vshift
    (drawing-group
     (drawing-scale
      drawing-unit-circle
      100)
     (drawing-scale
      (drawing-recolor drawing-unit-circle "yellow")
      90)
     (drawing-vshift
      (drawing-hscale
       (drawing-vscale
        drawing-unit-circle
        40)
       60)
      10)
     (drawing-hscale
      (drawing-vscale
       (drawing-recolor drawing-unit-circle "yellow")
       40)
      60)
     (drawing-vshift
      (drawing-group
       (drawing-hshift
        (drawing-group
         (drawing-hscale
          (drawing-vscale
           (drawing-recolor drawing-unit-circle "white")
           15)
          30)
         (drawing-hscale
          (drawing-vscale
           (drawing-recolor drawing-unit-circle "blue")
           15)
          15))
        18)
       (drawing-hshift
        (drawing-group
         (drawing-hscale
          (drawing-vscale
           (drawing-recolor drawing-unit-circle "white")
           15)
          30)
         (drawing-hscale
          (drawing-vscale
           (drawing-recolor drawing-unit-circle "green")
           15)
          15))
        -18))
      -15))
    50)
   50))

Believe it or not, but this code draws a smiley face.

Can you tell what part of the code generates what part of the face?

While the code sucessfully draws a smiley face, it is not very customizable - it draws only one size of smiley face, at only one location, and in only one way. Wouldn't it be much nicer if we could customize the face?

This weeks's second theme may sound a bit more straightforward: “Put a square peg in a round hole.” That is, we start with something like the following image:

How do we achieve this image? To solve the problem, we'll need to break it down into more manageable pieces.

Breaking down problems into manageable pieces is an essential skill computer scientists need. Once the pieces are small enough, you can implement them. And then you put the solution together from all the individual pieces you've solved.

But wait: There's more! Often, in the process of solving a clearly stated problem your imagination will run wild; and you will think of cool and beautiful things that you can do using the pieces you've created to solve the given problem. Then the creative artist in you can come out and express itself. So once you've done all we've specifically asked you to do, the final exercise will give you free rein to produce something beautiful, or at least compelling.

As we noted, the smiley code builds only one appearance of smiley face, with a fixed size and location. Wouldn't it be nice to be able to do more? Let's generalize that code!

Write a procedure, smiley, based on the code given above, that takes some inputs and draws a smiley face based on those inputs. Minimally, your procedure should have parameters that represent the the width, height, and center of the smiley face. But you may consider other possible inputs: eye color or shape, mouth color or shape, perhaps the size or relative position of some of the features.

Think carefully about naming the parameters you choose. Write 6Ps documentation so that we can understand how to use your procedure.

(a) Write a procedure (square-thing col row side-length color) that creates a drawing of a square with the specified side length whose top-left corner is at (col,row) and has the appropriate color.

(b) Write a procedure (round-thing col row diameter color) that creates a drawing of a circle with the specified diameter whose left margin is at col, whose top margin is at row, and which has the specified color.

(a) Write a procedure, (round-peg-in-square-hole col row side-length peg-color hole-color), which creates a square of the specified side length and top left corner at (col,row) with a circle that is as large as possible inserted. The square and peg should have the specified colors.

(image-show (drawing->image (round-peg-in-square-hole 20 20 50 "red" "black") 100 100))

(b) Centering the round peg in the square hole is easy, since both have the same width and the same height. But what if we want to center a smaller peg in the hole? We need to shift the peg so that the center matches the center of the hole. How do we do that? We could compute the coordinates of the center of the hole, and the center of the peg, and offset the peg the difference between those.

Write a procedure, (center-peg hole peg), that shifts peg to the center of the hole and then groups the two together.

(c) We're put a round peg in a square hole. Can we do the reverse? Can we put a square peg in a round hole? Since we know how to center the peg on the hole from the previous procedure, all we should need to know how to do is compute the size of the peg based on the size of the hole. But that's geometry that not all of us want to do. Fortunately, the Interweb tells us that the width of that square is the diameter of the circle divided by the square root of two.

(define square-peg-size
  (lambda (diameter-of-circular-hole)
    (/ diameter-of-circular-hole (sqrt 2))))

Using that procedure, as well as the center-peg procedure, write a procedure, (square-peg-in-round-hole col row diameter peg-color hole-color), which creates a circle of the specified diameter, with left margin at col, top margin at row, and with the largest possible square peg inserted. The square and peg should have the specified colors.

(image-show (drawing->image (square-peg-in-round-hole 20 20 50 "red" "black") 100 100))

With some (less than?) basic building blocks in place, you can now show off your creativity and imagination.

(a) Write code to generate two drawings as shown in the following two images. You may find it useful to write other helper procedures, such as one that creates a round peg in a square hole centered at a particular location.

(b) Use the techniques and procedures above, as well as any others you deem useful or interesting, write a program that generates an interesting image by combining at least four peg-in-hole drawings in any geometry or color arrangement you wish. Here is an example; your imagination should show there are many other possibile explorations, including many that include peg-and-hole arrangements other than pure nesting.
